H5-14, H5-15: BACnet Device Object Identifiers 0 and 1
These parameters set the Instance Identifier of the BACnet Device Object, where the H5-14 value is the least significant word
and the H5-15 value is the most significant word.
No. Name Setting Range Default
H5-14 BACnet Device Object Identifier 0 0 to FFFFH 1
H5-15 BACnet Device Object Identifier 1 0 to 3FH 0
Example 1: Set Device Object Instance Identifier of “1234”
1234 decimal is equal to 4D2H (hexadecimal)
Set H5-14 to 4D2H and set H5-15 to 0.
Example 2: Set Device Object Instance Identifier of “1234567”
12334567 decimal is equal to 12D687H
Set H5-14 to D687H and set H5-15 to 12H.
B.4 BACnet Setup Parameters
YASKAWA SIEP YAIZ1U 03B YASKAWA AC Drive – Z1000 Programming Manual
253
B
BACnet Communications

YASKAWA Z1000 CIMR-ZU*A Series Specifications

General

Series	Z1000 CIMR-ZU*A Series
Category	Controller
Voltage Classes	200V, 400V
Enclosure	NEMA 1, NEMA 12
Frequency Range	0.01 to 400 Hz
Cooling Method	Fan Cooled
Operating Temperature	-10°C to 50°C
Application	HVAC
Control Method	V/f Control
Input Voltage	200-240V, 380-480V
Frequency Range (Input)	50/60 Hz
Power Rating	0.4kW to 630kW
Protection Features	Overcurrent, Overvoltage, Undervoltage
Communication Options	Modbus
Storage Temperature	-20°C to 60°C
Humidity	5% to 95% (non-condensing)
Enclosure Rating	IP20
Output Voltage	0-100% of input voltage
