□Point-To-Point, EIA 232 (Clause 10), baud rate(s):
□Point-To-Point, modem, (Clause 10), baud rate(s):
□LonTalk, (Clause 11), medium:
□Other:
Device Address Binding:
Is static device binding supported? (This is currently necessary for two-way communication with MS/TP slaves and certain
other devices.) □Yes ■ No
Networking Options:
□Router, Clause 6 - List all routing configurations, e.g., ARCNET-Ethernet, Ethernet-MS/TP, etc.
□Annex H, BACnet Tunneling Router over IP
□BACnet/IP Broadcast Management Device (BBMD)
Does the BBMD support registrations by Foreign Devices? □Yes ■ No
Character Sets Supported:
Indicating support for multiple character sets does not imply that they can all be supported simultaneously.
■ ANSI X3.4
□ IBM/Microsoft
□ DBCS
□ ISO 8859-1
□ ISO 10646 (UCS-2)
□ ISO 10646 (UCS-4)
□ JIS C 6226
If this product is a communication gateway, describe the types of non-BACnet equipment/networks(s) that the gateway
supports: Not supported
B.11 BACnet Protocol Implementation Conformance Statement
YASKAWA SIEP YAIZ1U 03B YASKAWA AC Drive – Z1000 Programming Manual
265
B
BACnet Communications

YASKAWA Z1000 CIMR-ZU*A Series Specifications

General

Series	Z1000 CIMR-ZU*A Series
Category	Controller
Voltage Classes	200V, 400V
Enclosure	NEMA 1, NEMA 12
Frequency Range	0.01 to 400 Hz
Cooling Method	Fan Cooled
Operating Temperature	-10°C to 50°C
Application	HVAC
Control Method	V/f Control
Input Voltage	200-240V, 380-480V
Frequency Range (Input)	50/60 Hz
Power Rating	0.4kW to 630kW
Protection Features	Overcurrent, Overvoltage, Undervoltage
Communication Options	Modbus
Storage Temperature	-20°C to 60°C
Humidity	5% to 95% (non-condensing)
Enclosure Rating	IP20
Output Voltage	0-100% of input voltage
