Yealink WPP20 Administrator's Guide

| Configuring the Audio Settings | 157
Video Codec Bit Rate Frame
Rate
Frame Size
H.263+
Tx: CIF
Rx: CIF
H.265 (it is not
applicable to VP59)
Tx: 360P, 540P, 720P, 1080P
Rx: Conventional Size Below 1080P
APL-H.264-SVC(it
is only applicable to
Meeting Eye 600/
Meeting Eye 600/
PVT960/PVT940
running in Yealink
Cloud system)
100—3000
kbps
Tx: 360P, 40P, 720P
Rx: Conventional Size Below 720P
Note:
1. H.265 video codec is only applicable to a one-way video call, and the VCS cannot be connected
to a third-party camera. The VCS will negotiate with other parties to use the H264 High profile
video codec automatically when more people join the call.
2. The APL-H.264-SVC feature is only available when the Yealink Cloud server supports H.264-
SVC and you use the Meeting Eye 600/Meeting Eye 600/PVT960/PVT940 running in Yealink
Cloud system. Before using the APL-H.264-SVC feature, contact Yealink to subscribe to the
H.264-SVC service.
Tip: H.263 video codec consumes twice as much bandwidth as H.264 High profile video codec and
four times as much as H.265 video codec.
Configuring Video Codec
Procedure
1. On your web user interface, go to Account > Codec > Video Codec.
2. Configure and save the following settings:
Parameter Description Configuration Method
Enabled
Configure the enabled video
codec for the system to use.
Note: You can move the
disabled codec to this field.
Web user interface
Disabled
Configure the disabled video
codec.
Note: you can move the enabled
codec to this field.
Web user interface
SVC Enable (it is not applicable
to MeetingEye 600/MeetingEye
400/PVT960/PVT940/VC200/
VC200-E/VP59)
This feature is only applicable to
H.264/H.264 video codec.
Default: Disabled.
Web user interface

Yealink WPP20 Specifications

General

Interface	WLAN
USB version	2.0
Connectivity technology	Wireless
Wi-Fi	Yes
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
Security algorithms	WPA-PSK, WPA2-PSK
Networking standards	IEEE 802.11ac, IEEE 802.11b, IEEE 802.11n
Maximum data transfer rate	- Mbit/s
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave
Windows operating systems supported	Windows 10, Windows 7, Windows 8
Output voltage	5 V
Power consumption (typical)	2.5 W
Internal	No
Component for	Laptop
Product color	Gray
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	183.2 mm
Width	26 mm
Height	9 mm
