Yealink WPP20 Administrator's Guide

| Getting Started | 30
No. Name Description
19 Pound key Enter the pound key (#).
Related information
Using the Remote Control
VCC22 video conferencing camera
VCC22 is a video conferencing camera for VC880/VC800/PVT980. It adopts 12x optical zoom lens,
supports 1080P/60 frame full HD video, has OSMO and PTZ function, and possesses professional video
quality and environmental adaptability. You can connect up to 9 VCC22 video conferencing cameras to the
VC880/PVT980 video conferencing system, and 8 to VC800 video conferencing system.
The VCC22 camera can be panned (± 100 degrees range), tilted (± 30 degrees range) and supports 12 x
optical zoom, white balance and automatic gain.
• Front Panel of VCC22 Video Conferencing Camera
• Rear Panel of VCC22 Video Conferencing Camera
Front Panel of VCC22 Video Conferencing Camera
The LED indicator in front of the camera indicates different camera status.
Related information
LED Instructions of VCC22 Video Conferencing Camera

Yealink WPP20 Specifications

General

Interface	WLAN
USB version	2.0
Connectivity technology	Wireless
Wi-Fi	Yes
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
Security algorithms	WPA-PSK, WPA2-PSK
Networking standards	IEEE 802.11ac, IEEE 802.11b, IEEE 802.11n
Maximum data transfer rate	- Mbit/s
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave
Windows operating systems supported	Windows 10, Windows 7, Windows 8
Output voltage	5 V
Power consumption (typical)	2.5 W
Internal	No
Component for	Laptop
Product color	Gray
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	183.2 mm
Width	26 mm
Height	9 mm
