Yealink WPP20 Administrator's Guide

| Getting Started | 31
Rear Panel of VCC22 Video Conferencing Camera
Port Name Description
1 HDMI Out Connect to a monitor for displaying shared content.
2 Camera Port Connect to a PoE switch.
3 Reset Key Reset the camera to factory defaults.
4 Security Slot Allow you to connect a universal security cable to VCC22, so you can lock it
down. The camera cannot be removed when locked.
Hardware of VCH50 Video Conferencing Hub
You can connect VCH50 to the computer for presenting. If you want to connect a PC to your system using
Ethernet cable, you need to connect the VCH50 video conferencing hub to your system. Connecting
VCH50 to the computer for presenting is not applicable to VP59.
• Left Side of VCH50 Cable Hub
• Right Side of VCH50 Cable Hub
• Rear Panel of VCH50 Cable Hub
Left Side of VCH50 Cable Hub
Port Name Description
1 Codec Connect to the video conferencing
system via the provided 7.5m network
cable.

Yealink WPP20 Specifications

General

Interface	WLAN
USB version	2.0
Connectivity technology	Wireless
Wi-Fi	Yes
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
Security algorithms	WPA-PSK, WPA2-PSK
Networking standards	IEEE 802.11ac, IEEE 802.11b, IEEE 802.11n
Maximum data transfer rate	- Mbit/s
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave
Windows operating systems supported	Windows 10, Windows 7, Windows 8
Output voltage	5 V
Power consumption (typical)	2.5 W
Internal	No
Component for	Laptop
Product color	Gray
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	183.2 mm
Width	26 mm
Height	9 mm
