Yealink WPP20 Administrator's Guide

| Configuring the Audio Settings | 159
Transmission Ways of DTMF
Three ways to transmit DTMF tones are as below: RFC2833, INBAND, SIP INFO.
RFC 2833
In-band transmission method. DTMF tones are transmitted by RTP, and the RFC 2833 packets are marked
by TeleponeEvent (RTP PayloadType). One DTMF tone consists of several RTP packets with the same
timestamps, which can be used to identify the same key. If the End bit of a RTP packet is 1, the packet is
the last DTMF tone. The default telephoneEvent is 101, but you can change it.
INBAND
In-band transmission method. DTMF tones are transmitted together with the voice band. By analyzing the
high frequency and the low frequency of the RTP packets, the device can identify the corresponding key.
SIP INFO
Out-band transmission method. DTMF tones are transmitted by SIP signaling path. The SIP INFO
message can transmit DTMF tones in three ways: DTMF, DTMF-Relay and Telephone-Event.
Setting DTMF Transmission Method for SIP Protocol
You can set the DTMF transmission method for the SIP protocol when using a SIP account, placing SIP IP
call, or logging in to Zoom, Pexip, BlueJeans, EasyMeet, or a custom third-party platform.
Procedure
1. Do one of the following:
• On your web user interface, go to Account > SIP Account/SIP IP Call.
• On your web user interface, go to Account > VC Platform > Platform Type > Zoom/Pexip/
BlueJeans/Custom.
• On your VCS devices: go to More > Settings > Advanced > Account > SIP IP Call.
On your VP59, tap > Settings > Advanced > Account > SIP IP Call.
•
On your CTP20/CTP18, tap > Settings > Advanced > Account > SIP IP Call.
2. Configure and save the following settings:
Parameter Description Configuration Method
DTMF Type
Configure the DTMF type.
• INBAND—DTMF is transmitted in the
voice band, together with the general
RTP voice packet.
• RFC2833—DTMF digits are
transmitted by RTP packet which is
compliant to RFC2833.
• SIP INFO—DTMF digits are
transmitted by SIP INFO.
• RFC2833+ SIP INFO—DTMF digits
are transmitted by RFC 2833 and the
SIP INFO.
Default: RFC2833.
Web user interface
Endpoint (remote control/VP59)
CTP20/CTP18

Yealink WPP20 Specifications

General

Interface	WLAN
USB version	2.0
Connectivity technology	Wireless
Wi-Fi	Yes
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
Security algorithms	WPA-PSK, WPA2-PSK
Networking standards	IEEE 802.11ac, IEEE 802.11b, IEEE 802.11n
Maximum data transfer rate	- Mbit/s
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave
Windows operating systems supported	Windows 10, Windows 7, Windows 8
Output voltage	5 V
Power consumption (typical)	2.5 W
Internal	No
Component for	Laptop
Product color	Gray
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	183.2 mm
Width	26 mm
Height	9 mm
