| Getting Started | 28

Name Description

⑦

Back Key Return to the previous menu.

⑧

Volume Key Turn up/down the volume.

Introduction of VCR11 Remote Control

The VCR11 remote control allows you to operate a video conferencing system, including placing calls,

adjusting EQ volume, controlling the camera, navigating screens, and more. The following table introduces

the keys on the remote control.

Default Chapter2
