Yealink WPP20 Administrator's Guide

| Getting Started | 27
Name Description
①
Custom Key
Customize the key function.
You can configure this key as the Presentation, the Tracking mode,
the ScreenShot, the Mute, the Preset, or the Camera Control key.
Note: for second generation VCS devices, it defaults to
Presentation key; for third generation VCS devices, it defaults to
Camera Control key.
②
Mute Key Mute or unmute the microphone
③
Navigation Key
• Navigate through menu items.
• Pan and tilt the camera to adjust the viewing angle.
④
Scroll Wheel (OK Key)
• Scroll up or down to the desired menu item. Press the key to go
to the sub-menu or confirm actions.
• Zoom in/out the camera: After selecting the video, scroll up or
down to zoom in/out the video image.
⑤
Hang up key
• End a call or exit the current conference.
• Return to the idle screen.
• Long press to shut down the system or put the system to sleep.
• Press it to power on the endpoint when the endpoint is shut
down but not powered off.
⑥
Answer key Go to the Pre-dialing screen, place a call or answer a call.

Yealink WPP20 Specifications

General

Interface	WLAN
USB version	2.0
Connectivity technology	Wireless
Wi-Fi	Yes
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
Security algorithms	WPA-PSK, WPA2-PSK
Networking standards	IEEE 802.11ac, IEEE 802.11b, IEEE 802.11n
Maximum data transfer rate	- Mbit/s
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave
Windows operating systems supported	Windows 10, Windows 7, Windows 8
Output voltage	5 V
Power consumption (typical)	2.5 W
Internal	No
Component for	Laptop
Product color	Gray
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	183.2 mm
Width	26 mm
Height	9 mm
