Yealink WPP20 Administrator's Guide

| Getting Started | 33
Left Side of VCH51 Cable Hub
Port Name Description
1 PC port Connect to PC via Type-C cable for content sharing.
2 HDMI Connect to PC via HDMI cable for sharing contents.
Right Side of VCH51 Cable Hub
Port Name Description
1 PoE Connect to the VC Hub/Phone port on the VCS codec or to
the PoE.
CP960 Conference Phone
You can use CP960 conference phone as a microphone and a speaker when you are having a call on
VC200/VC200-E/VC500/VC800/VC880/PVT980/PVT950. You can also place calls, answer calls or view
directory and history on CP960.

Yealink WPP20 Specifications

General

Interface	WLAN
USB version	2.0
Connectivity technology	Wireless
Wi-Fi	Yes
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
Security algorithms	WPA-PSK, WPA2-PSK
Networking standards	IEEE 802.11ac, IEEE 802.11b, IEEE 802.11n
Maximum data transfer rate	- Mbit/s
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave
Windows operating systems supported	Windows 10, Windows 7, Windows 8
Output voltage	5 V
Power consumption (typical)	2.5 W
Internal	No
Component for	Laptop
Product color	Gray
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	183.2 mm
Width	26 mm
Height	9 mm
