Yealink WPP20 Administrator's Guide

| Managing the Directory | 228
Parameter Description Configuration Method
LDAP Name Filter
Configure the name attribute for
LDAP searching.
Example: (|(cn=%)(sn=%))
Web user interface
LDAP Number Filter
Configure the number attribute
for LDAP searching.
Example: (|(telephoneNumber=
%)(mobile=%))
Web user interface
LDAP TLS Mode
Configure the connection mode
between the LDAP server and
the system.
• LDAP—Unencrypted
connection between LDAP
server and the system (port
389 is used by default).
• LDAP TLS Start- TLS/SSL
connection between LDAP
server and the system (port
389 is used by default).
• LDAPs- TLS/SSL connection
between LDAP server and
the system (port 636 is used
by default).
Default: LDAP
Web user interface
LDAP Server Address Configure the domain name
or the IP address of the LDAP
server.
Web user interface
Port
Configure the LDAP server port.
Default: 389.
Web user interface
LDAP User Name
Configure the user name used to
log into the LDAP server.
Note: the user name is
provided by the LDAP server
administrator. If the LDAP server
allows ‘anonymous’ to login,
you don’t need to provide the
user name to access the LDAP
server.
Web user interface

Yealink WPP20 Specifications

General

Interface	WLAN
USB version	2.0
Connectivity technology	Wireless
Wi-Fi	Yes
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
Security algorithms	WPA-PSK, WPA2-PSK
Networking standards	IEEE 802.11ac, IEEE 802.11b, IEEE 802.11n
Maximum data transfer rate	- Mbit/s
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave
Windows operating systems supported	Windows 10, Windows 7, Windows 8
Output voltage	5 V
Power consumption (typical)	2.5 W
Internal	No
Component for	Laptop
Product color	Gray
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	183.2 mm
Width	26 mm
Height	9 mm
