Specifications
18
18.4 External Input/Output Section (TRIG/SWEEP/
CTRL IN and OUT)
Connector type: BNC connector, D-Sub 15-pin receptacle
Input/output level: TTL
I/O logic format: Negative logic, falling edge
Minimum pulse width: 10 µs or greater
18.5 Interface
GP-IB Interface
Electrical and mechanical specifications: Conforms to IEEE St’d 488-1987
Functional specifications: SH1, AH1, T6, L4, SR1, RL1, PP0, DC1, DT1,
and C0
Protocol: Conforms to IEEE St’d 488.2-1987
Address: 0 to 30
RS-232 Interface
Connector type: D-Sub 9-pin
Electrical specifications: Conforms to EIA RS-232
Connection format: Point-to-point
Transmission mode: Full-duplex
Synchronization mode: Start-stop synchronization
Baud rate: 9600, 14400, 19200, 38400, 57600, and
115200 bps
USB Interface
Number of ports: 1
Connector type: Type B connector (receptacle)
Electrical and mechanical specifications: Conforms to USB Rev. 2.0
Ethernet Interface (Option)
Number of communication ports: 1
Connector type: RJ-45 connector
Electrical and mechanical specifications: Conforms to IEEE 802.3.
Transmission system: 100BASE-TX/10BASE-T
Data rate: 100 Mbps/10 Mbps
