18.3 Functions
Source
Source function: Voltage and current
Source mode: DC or pulse
Sweep mode: Linear, logarithmic, or program (up to 65535
steps)
Measurement
Measurement function: Voltage, current, and resistance (calculated
from measured voltage/generated current or
generated voltage/measured current)
Measurement data storage: Up to 65535 data points
Averaging: Block average or moving average at the
specified count (2 to 256)
Trigger
Trigger mode: Internal trigger, external trigger, and
immediate
Time Setting
Pulse width: 100 µs to 3600 s 1 µs resolution
Repeat period: 100 µs to 3600 s 1 µs resolution
Source delay: 1 µs to 3600 s 1 µs resolution
Measurement delay: 1 µs to 3600 s 1 µs resolution
Integration time: 250 µs, 1 ms, 4 ms, 16.6 ms or 20 ms, 100 ms,
200 ms
Auto detect from the power supply frequency
when the power is turned ON for 16.6 ms and
20 ms
Computation
Computation Using Equations
Loads the equation definition file created in text format and performs the computation
Five built-in equations are pre-installed
Operators: +(addition), -(subtraction), *(multiplication), /
(division), and ^ (exponentiation)
Functions: abs() (absolute value), exp() (exponent of e),
In() (natural logarithm), log (log base 10),
sqrt() (square root), sin(), cos(), tan(), asin(),
acos(), atan(), sinh(), cosh(), and tanh()
NULL Computation
Sets the NULL value to the measured value when the NULL computation is turned ON,
and displays values obtained by subtracting the NULL value from the measured value for
subsequent measurements.
Comparison Operation
Determines the magnitude relation between the displayed value and the reference
values (upper and lower) and displays the result.
