18-6 IM 765501-01E
18.6 General Specifications
Safety Standards
1
Complying standard
EN61010-1, EN61010-2-030
Overvoltage category (Installation category) II
2
Measurement category Other(O)
3
Pollution degree 2
4
Emissions
1
Complying standard
EN61326-1 Class A
EN55011 Class A, Group 1
EN61000-3-2 Class A
EN61000-3-3
EMC Regulatory Arrangement in Australia and New Zealand
Korea Electromagnetic Conformity Standard
This is a Class A product. In a domestic environment this productmay cause radio
interference in which case the user may be required to take adequate measures.
Cable condition
• Output terminal
Use a measurement lead (758933, red and black 1pc, length: 1 m) of the standard
accessories for connection.
Connection of sense terminal at the time of 4 terminal connection also recommends
use of this cable. (Use a cable of length 1 m or less.)
• BNC IN/OUT terminal
For connection, use a BNC cable that is better than or equivalent to the 1.5D-QEW
BNC cable.
5
• ETHERNRT port
Use a five or more-category LAN cable for connection.
• USB port
Use a cable corresponding to USB 2.0 (Hi-speed USB) for connection.
5
• GP-IB connector
Use a GP-IB (IEEE488) cable for connection.
• EXT I/O connector
Use a shielded cable for connection.
5
• SERIAL (RS-232) connector
Use a RS-232 shielded cable for connection.
Immunity
1
Complying standard
EN61326-1 Table2
6
• Immunity influence
Within the measured value ±20% of range
• Test condition
100-V range, DC sourse mode, limit: ±0.5 A, resistance under measurement: 220 Ω,
local sense (2W)
However, a cable is connected also to sense terminal and others are set up at the
factory default setup.
(Cable conditions examined on the same conditions as emission.)
Environmental standard
Compliant standard
EN50581 Monitoring and control instruments including monitoring and control instruments.
