App-18 IM 765501-01E
Appendix 3 Contents of the Factory Default Setup
File (Default.txt)
Item Setting
Source Mode DC
Function Voltage source
Auto range OFF
Voltage range setting 2 V
Voltage level 0 V
Voltage pulse base 0 V
Current range setting 2 mA
Current level 0 mA
Current pulse base 0 mA
Voltage zero offset 0 mV
Current zero offset 0 uA
Voltage zero impedance LoZ
Current zero impedance HiZ
Limiter ON
Tracking ON
Current high limit 2 mA
Current low limit –2 mA
Voltage high limit 2 V
Voltage low limit –2 V
Sweep Mode OFF
Voltage start value 100 mV
Voltage step value 10 mV
Voltage stop value 200 mV
Voltage log sweep step 10
count
Current start value 1 µA
Current step value 0.1 µA
Current stop value 2 µA
Current log sweep step 10
count
Repeat count 1
Termination mode Keep
Trigger Trigger mode Int
(internal trigger)
Measurement ON
Function Current
Auto range OFF
Integration time 16.6/20 ms
Auto zero ON
Store OFF
Auto store OFF
Store count 10
Auto V/I OFF
Averaging mode OFF
Average count 2
NULL OFF
NULL value 0
Time Source delay 1 µs
Measurement Delay 50 µs
Pulse width 25 ms
Repeat period of the 50 ms
internal trigger
Computation using equations OFF
Param A 0
Param B 0
Param C 0
Comparison operation OFF
Upper 0
Lower 0
Item Setting
External BNC input terminal setting Trig
input/output BNC output terminal setting Trig
Trig setting of the BNC Origin
output terminal
DIO5 input connector Output
setting
DIO6 output connector Origin
setting
DIO7 output connector Origin
setting
DIO8 output connector IntLock
setting
Others Connection type 2W
Beep sound ON
Display brightness 4
