Procedure
Preparation
Set the GS610 as follows:
Setup Example of the GS610
SOURCE Output function Current output
Limiter value 3 V
Output mode Pulse
Output range AUTO
OUTPUT CONTROL Trigger mode Internal
MEASURE Measurement function Voltage measurement
Integration time 250 µs
Measurement range AUTO
AUTO V/I ON
(auto switching of the measurement mode)
Store count 65535 points
TIME Source delay 1 µs
Measurement delay 1 µs
Repeat period (of the internal trigger) 40 ms
Pulse width 5 ms
Source and Measurement
1. The GS610 outputs (sinks) the pulse current to the secondary battery and
measures the voltage.
The source values and measured results are saved to a single file in the internal
memory of the GS610 (GS610RAM).
2. Transfer (Copy) the measurement result file from the GS610RAM to the PC via
the USB.
Appendix 2 Application Examples
