16.2.5 Measurement Commands (SENSe GRoup)
:SENSe:ITIMe
Function Sets the integration time or queries the current
setting.
Syntax :SENSe:ITIMe <Time>|PLC|MINimum|
MAXimum|UP|DOWN
<Time> = Sets the smallest integration time that
includes the specified value.
PLC = Sets the integration time to 1 cycle of the
power frequency.
MINimum = Sets the integration time to the
minimum value.
MAXimum = Sets the integration time to the
maximum value.
UP = Increases the integration time by 1 setting.
DOWN = Decreases the integration time by 1
setting.
:SENSe:ITIMe? [MINimum|MAXimum]
No parameter = Queries the current value.
MINimum = Queries the minimum value.
MAXimum = Queries the maximum value.
→ <Time>
Example :SENS:ITIM 4E-3
:SENS:ITIM MIN
:SENS:ITIM?
:SENS:ITIM? MIN
:SENSe:DELay
Function Sets the measurement delay or queries the
current setting.
Syntax :SENSe:DELay <Time>|MINimum|MAXimum
<Time> = Sets the measurement delay to the
specified value.
MINimum = Sets the measurement delay to the
minimum value.
MAXimum = Sets the measurement delay to the
maximum value.
:SENSe:DELay? [MINimum|MAXimum]
No parameter = Queries the current value.
MINimum = Queries the minimum value.
MAXimum = Queries the maximum value.
→ <Time>
Example :SENS:DEL 2.5E-3
:SENS:DEL MIN
:SENS:DEL?
:SENS:DEL? MAX
:SENSe[:STATe]
Function Sets the measurement state (ON or OFF) or
queries the current setting.
Syntax :SENSe[:STATe] 1|0|ON|OFF
1 or ON = Turns the measurement ON.
0 or OFF = Turns the measurement OFF.
:SENSe[:STATe]?
→ 1 = Currently ON
0 = Currently OFF
Example :SENS:STAT OFF
:SENS:STAT?
:SENSe:FUNCtion VOLTage|CURRent|
RESistance
Function Sets the measurement function (voltage,
current, or resistance) or queries the current
setting.
Syntax :SOURce:FUNCtion VOLTage|CURRent|
RESistance
VOLTage = Sets the measurement function to
voltage.
CURRent = Sets the measurement function to
current.
RESistance = Sets the measurement function to
resistance.
:SOURce:FUNCtion?
→ VOLT = Currently set to voltage.
CURR = Currently set to current.
RES = Current set to resistance.
Example :SENS:FUNC RES
:SENS:FUNC?
:SENSe:RANGe:AUTO
Function Sets the measurement auto range (ON or OFF)
or queries the current setting.
Syntax :SENSe:RANGe:AUTO 1|0|ON|OFF
1 or ON = Turns auto range ON.
0 or OFF = Turns auto range OFF.
:SENSe:RANGe:AUTO?
→ 1 = Currently ON
0 = Currently OFF
Example :SENS:RANG:AUTO OFF
:SENS:RANG:AUTO?
