18-3
IM 765501-01E
Specifications
3
2
1
6
5
4
9
8
7
12
11
10
15
14
13
18
18
17
16
Index
App
18.2 Measurement Section
Voltage Measurement
Integration Time of 16.66 ms/20 ms, 100 ms, or 200 ms
Range Measurement Resolution Accuracy (One Year) Temperature Coefficient
Setting Range ±(% of reading+V) ±(% of reading+V)/°C
200 mV ±205.000 mV 1 µV 0.02+100 µV 0.002+30 µV
2 V ±2.05000 V 10 µV 0.02+200 µV 0.002+20 µV
20 V ±20.5000 V 100 µV 0.02+1 mV 0.002+100 µV
110 V ±110.000 V 1 mV 0.02+10 mV 0.002+1 mV
Integration time of 4 ms, 1 ms, or 250 µs
Range Measurement Resolution Accuracy (One Year) Temperature Coefficient
Setting Range ±(% of reading+V) ±(% of reading+V)/°C
200 mV ±205.00 mV 10 µV 0.02+200 µV (300 µV) 0.002+20 µV (30 µV)
2 V ±2.0500 V 100 µV 0.02+300 µV (500 µV) 0.002+30 µV (50 µV)
20 V ±20.500 V 1 mV 0.02+3 mV (5 mV) 0.002+300 µV (500 µV)
110 V ±110.00 V 10 mV 0.02+30 mV (50 mV) 0.002+3 mV (5 mV)
Accuracy: One year accuracy at 23±5°C with auto zero turned ON.
Temperature coefficient: Add the temperature coefficient at 5 to 18°C and 28 to 40°C.
Values inside the parentheses are those when those when the integration time 1 ms or 250 µs.
Current Measurement
Integration Time of 16.66 ms/20 ms, 100 ms, or 200 ms
Range Measurement Resolution Accuracy (One Year) Temperature Coefficient
Setting Range ±(% of reading+A) ±(% of reading+A)/°C
20 µA ±20.5000 µA 100 pA 0.03+50 nA 0.003+5 nA
200 µA ±205.000 µA1 nA 0.03+300 nA 0.003+30 nA
2 mA ±2.05000 mA 10 nA 0.03+3 µA 0.003+300 nA
20 mA ±20.5000 mA 100 nA 0.03+30 µA 0.003+3 µA
200 mA ±205.000 mA 1 µA 0.03+300 µA 0.003+30 µA
3 A ±3.20000 A 10 µA 0.03+5 mA 0.003+500 µA
Integration time of 4 ms, 1 ms, or 250 µs
Range Measurement Resolution Accuracy (One Year) Temperature Coefficient
Setting Range ±(% of reading+A) ±(% of reading+A)/°C
20 µA ±20.500 µA1 nA 0.03+70 nA (80 nA) 0.003+7 nA (8 nA)
200 µA ±205.00 µA 10 nA 0.03+350 nA (400 nA) 0.003+35 nA (40 nA)
2 mA ±2.500 mA 100 nA 0.03+3.5 µA (4 µA) 0.003+350 nA (400 nA)
20 mA ±20.500 mA 1 µA 0.03+35 µA (40 µA) 0.003+3.5 µA (4 µA)
200 mA ±205.00 mA 10 µA 0.03+350 µA (400 µA) 0.003+35 µA (40 µA)
3 A ±3.2000 mA 100 µA 0.03+5.5 mA (6 mA) 0.003+550 µA (600 µA)
Accuracy: One year accuracy at 23±5°C with auto zero turned ON.
Temperature coefficient: Add the temperature coefficient at 5 to 18°C and 28 to 40°C.
Values inside the parentheses are those when those when the integration time 1 ms or 250 µs.
