Optional Accessories (Sold Separately)
The optional accessories below are available for purchase separately.
Name Model/ Min. Safety Notes Manual No.
Part No. Q’ty standard
Measurement lead 758917 1 set 1000 V CAT II Safety terminal cable with 2 leads (red and black) —
in a set. Length: 0.75 m. Rating: 1000 V, 32 A.
758933 1 set 1000 V CAT III Safety terminal cable with 2 leads (red and black) —
in a set. Length: 1 m. Rating: 1000 V, 19 A.
Alligator clip adapter 758922 1 set 300 V CAT II Safety terminal-to-alligator clip adapter. Red and —
(small) black, 1 pc each. Rating: 300 V, 15 A.
Alligator clip adapter 758929 1 set 1000V CAT II Safety terminal-to-alligator clip adapter. Red and —
(large) black, 1 pc each. Rating: 1000 V, 32 A.
Safety terminal adapter 758923 1 set 600 V CAT II Spring clamp type. Red and black, 1 pc. each. —
Rating: 600 V, 10 A.
758931 1 set 1000 V CAT III Screw-in type. Red and black, 1 pc each. —
Rating: 1000 V, 36 A.
Conversion adapter 758924 1 500 V CAT II Safety BNC-to-banana adapter. Rating: 500 V. —
BNC cable 366924 1 — BNC-BNC, length: 1 m. Rating: 42 V. —
366925 1 — BNC-BNC, length: 2 m. Rating: 42 V. —
D-sub connector for A1519JD 1 — 15-pin connector cover —
External I/O B8060KA 1 — 15-pin connector —
WARNING
• Use the accessories specified in this manual. Moreover, use the accessories of
this product only with Yokogawa products that specify them as accessories.
• Use the accessories of this product within the rated range of each accessory.
When using several accessories together, use them within the specification
range of the accessory with the lowest rating.
CAUTION
Use BNC cables 366924 and 366925 for the BNC I/O terminals.
French
AVERTISSEMENT
• Utiliser les accessoires spécifiés dans ce manuel. En outre, utiliser les
accessoires de ce produit uniquement avec des produits Yokogawa pour
lesquels ils sont spécifiés comme accessoires.
• Utilisez les accessoires de ce produit en fonction des valeurs nominales de
chacun.
Lorsque vous employez plusieurs accessoires en même temps, utilisez les
valeurs de l’accessoire ayant les valeurs nominales les plus faibles.
ATTENTION
Utiliser les câbles BNC 366924 et 366925 pour les bornes E/S BNC.
