14-6
IM DLM3054-01EN
Pulse Width Search
Search Source Waveform (Source)
You can select from one of the settings below. The available settings vary depending on the model.
CH1 to CH4/LOGIC,* Math1 to Math4
* CH4 or LOGIC, whichever the corresponding key is illuminated, can be selected. If you select LOGIC, select
the source bit (bit 0 to bit 7).
Reference Time (Time)
Selectable range: 1 ns to 10 s
Polarity (Polarity), Time Condition (Mode)
This item is the same as that of the Pulse Width trigger.
Level (Level) and Hysteresis (Hys)
Set the level and hysteresis used to detect the search source waveform state.
These items are the same as those of the edge search.
Timeout Search
Search Source Waveform (Source)
You can select from one of the settings below. The available settings vary depending on the model.
CH1 to CH4/LOGIC,* Math1 to Math4
* CH4 or LOGIC, whichever the corresponding key is illuminated, can be selected. If you select LOGIC, select
the source bit (bit 0 to bit 7).
Timeout Period (Time)
Selectable range: 1 ns to 10 s
Polarity (Polarity)
Select which polarity will cause the comparison with the timeout period. The search source polarity is based on
the level.
Pos (positive polarity)
Neg (negative polarity)
Level (Level) and Hysteresis (Hys)
Set the level and hysteresis used to detect the search source waveform state.
These items are the same as those of the edge search.
14 Searching Waveforms
