Search Setup (Search)
Search Type (Mode)
Select the SENT signal search type from one of the settings below.
• Every Fast CH: Searches for fast channel messages
• Fast CH S&C: Searches for the status and communication bit pattern
• Fast CH Data: Searches for the position where the AND condition of the fast channel data is met
• Every Slow CH: Searches for slow channel messages
• Slow CH ID/Data: Searches for the position where the AND condition of the slow channel ID and data is met
• Error: Searches for errors
The method to set search conditions is the same as that for the trigger conditions of the SENT trigger. Set the ID
and data using the format selected in the decode menu.
Executing a Search (Search)
The instrument searches for locations where the specified search conditions are met. Then, the instrument
displays the specified detected point number (Pattern No) expanded in the zoom window.
Detected Points
For the positions of detected points, see appendix 6.
15 Analyzing and Searching Serial Bus Signals
