Configuring the Display (Display Setup)
Set the trend display scale, and turn the display of VT waveforms on or off.
• Auto Scale Exec
Executes auto scaling. The upper and lower limits are set so that the difference between the maximum data
value and minimum data value in the window selected with H-Range covers 80% of the vertical scale of the
Trend window.
• H-Range
Select the range to display the trend of from the following windows.
Main: Main window
Zoom1: Zoom1 window
Zoom2: Zoom2 window
• VT Display
Select whether to display the VT waveform along with the trend display.
ON: Displays the VT waveform display window
OFF: Does not display the VT waveform display window
• Upper/Lower
Set the vertical scale values of the trend display.
• Cursor Measurement (Cursor)
You can perform cursor measurement on the trend.
ON: Cursor1 and Cursor2 values are measured.
OFF: Cursor measurement is not performed.
T1 Time value of Cursor1 (time from the trigger position*)
T2 Time value of Cursor2 (time from the trigger position*)
ΔT Difference between the time values of Cursor1 and Cursor2
V1(TRx) Data value at the intersection of Cursor1 and trend (Trend) x
V2(TRx) Data value at the intersection of Cursor2 and trend (Trend) x
ΔV(TRx) Difference between the data values at the intersection of Cursor1 and
trend (Trend) x and the intersection of Cursor2 and trend (Trend)
* If delay cancel (Delay Cancel) is set to OFF, they are based on the trigger point.
x: 1 to 4
