20-7
IM DLM3054-01EN
FFT Computation Results (FFT)
You can save the results of computation that was specified using FFT1 or FFT2 in CSV format. The extension is
.csv. Up to 250 Kpoints of data can be saved.
Freq Info.
• OFF: The results are saved without frequency information.
Data size in bytes = The number of data points × 15
• ON: All data is saved with frequency information.
Data size in bytes = The number of data points × 30
Output Example
Analysis Type FFT
Model Name DLM3000
Model Version *.**
Data Points 6251
HResolution 5.00E+00
HUnit Hz
-3.10E+01
-5.43E+01
-4.16E+01
-6.69E+01
-4.80E+01
-5.26E+01
-6.39E+01
-5.11E+01
-5.17E+01
-5.87E+01
(When Freq Info. is set to OFF)
Analysis Type FFT
Model Name DLM3000
Model Version *.**
Data Points 6251
HResolution 1.00E+02
HUnit Hz
0.00E+00 -5.48E+01
1.00E+02 -7.27E+01
2.00E+02 -5.84E+01
3.00E+02 -7.79E+01
4.00E+02 -6.12E+01
5.00E+02 -6.14E+01
6.00E+02 -6.02E+01
7.00E+02 -6.58E+01
8.00E+02 -6.18E+01
9.00E+02 -6.53E+01
(When Freq Info. is set to ON)
Histogram (Histogram)
You can save the histogram of the waveform or the waveform parameter that was specified using Hist1 or Hist2.
List of Timestamps (History List)
You can save the list of history waveform information—record number, trigger time, and the difference between
the trigger times of the history waveform and its previous history waveform—in CSV format. The extension is
.csv.
Data size in bytes = The number of history waveforms × 72
Output Example
Data Type
Model Name
Model Version
Start No.
End No.
No.
0
-1
-2
-3
-4
-5
-6
-7
-8
-9
-10
Delta
0.006 000
0.008 000
0.006 000
0.006 000
0.015 002
0.006 000
0.006 000
0.006 000
0.006 000
0.036 000
0.005 998
DLM3000
*.**
0
-99
Trig'd Time
16:12:08.407 320
16:12:08.401 320
16:12:08.393 320
16:12:08.387 320
16:12:08.381 318
16:12:08.366 318
16:12:08.360 318
16:12:08.354 318
16:12:08.348 318
16:12:08.342 318
16:12:08.306 320
20 Saving and Loading Data
