YOKOGAWA DLM3024 User Manual

20-12
IM DLM3054-01EN
Output example of a Slow CH List
Analysis Type SerialBus(SENT)
Model Name DLM3000
Model Version *.**
No. Time(ms) ID Data CRC Information
-3 -45.94672 6 3 0D
-2 -30.6392 1 205 0B
-1 -15.31336 2 900 28
0 -0.01192 88 201 20
1 15.48904 1 206 1A
2 31.01336 2 930 30
Hexadecimal or decimal display of data
Amount of time from the trigger position to the start of frame
Hexadecimal or decimal display of ID
Error information
Analysis number
Hexadecimal or decimal display of CRC
UART
You can save analysis results of UART signals to a file in CSV format. The extension is .csv. Analysis results of
up to 300000 bytes can be saved.
Data size* = (The number of frames in analysis results + 4) × 40 bytes
* The data size is for reference. It is not strictly warranted. Use this as reference for saving data.
Output Example (when grouping is set to ON)
Data1 in hexadecimal
Amount of time from the start point
Analysis number
Analysis Type SerialBus(UART)
Model Name DLM3000
Model Version *.**
No. Time(ms) Data(HEX)
Data(ASCII) Information
-4 -209.948 00 80 40 C0 20 04 84 44 ... ..@. ..D.$..L.,..B."
-3 -157.864 00 80 40 C0 20 04 84 44 ... ..@. ..D.$..L.,..B."
-2 -105.78 00 80 40 C0 20 04 84 44 ... ..@. ..D.$..L.,..B."
-1 -53.696 00 80 40 C0 20 04 84 44 ... ..@. ..D.$..L.,..B."
0 -1.612 00 80 40 C0 20 04 84 44 ... ..@. ..D.$..L.,..B."
1 50.468 00 80 40 C0 20 04 84 44 ... ..@. ..D.$..L.,..B."
2 102.552 00 80 40 C0 20 04 84 44 ... ..@. ..D.$..L.,..B."
3 154.636 00 80 40 C0 20 04 84 44 ... ..@. ..D.$..L.,..B."
4 206.72 00 80 40 C0 20 04 84 44 ... ..@. ..D.$..L.,..B."
Data1 in ASCII
Error information
Framing Error
Parity Error
20 Saving and Loading Data
