20-13
IM DLM3054-01EN
I
2
C
You can save analysis results of I
2
C bus signals to a file in CSV format. The extension is .csv. Analysis results of
up to 300000 bytes can be saved.
Data size* = (The number of bytes in the analysis results / 2 + 4) × 125 bytes
* The data size is for reference. It is not strictly warranted. Use this as reference for saving data.
Output Example
Address type
Amount of time from the trigger position
Read/Write bit state
(W stands for write; R stands for data request.)
Analysis number
Analysis result in hexadecimal
Analysis Type SerialBus(I2C)
Model Name DLM3000
Model Version *.**
No. Time(ms) 1st 2nd R/W Data Information
-4 -208.116 AA* W AE* 8B*
-3 -156.036 75* R BC* EF
-2 -103.952 38* W 53* A9*
-1 -51.868 9D* R 10* 4B
* ACK present
SPI
You can save analysis results of SPI bus signals to a file in CSV format. The extension is .csv. Analysis results of
up to 300000 bytes can be saved.
Data size* = (The number of bytes in the analysis results × 2 + 4) × 125 bytes
* The data size is for reference. It is not strictly warranted. Use this as reference for saving data.
Output Example
Data1 in hexadecimal
Amount of time from the start point
Analysis number
Analysis Type SerialBus(SPI)
Model Name DLM3000
Model Version *.**
No. Time(ms) Data
-6 -0.65304 Data1 00 00 00 00 00 7F FF FF FF FF FF FF F8 00
-5 -0.63704 Data1 FF E0 00 3F FF FF FF FF FF FF FC 00 07 FF
......
-4 -0.60504 Data1 FF E0 00 00 00 7F FF 00 00 00 03 FF FF FF ......
-3 -0.25304 Data1 00 1F FF C0 00 7F FF 00 01 FF FF FF FF FF
-2 -0.23704 Data1 FF FF FF C0 00 00 00 00 00 00 03 FF F8 00 ......
-1 -0.20504 Data1 00 1F FF FF FF 80 00 FF FE 00 03 FF F8 00 ......
0 0.14696 Data1 00 00 00 3F FF FF FF FF FE 00 03 FF FF FF
1 0.16296 Data1 00 1F FF FF FF FF FF FF FF FF FC 00 07 FF
......
2 0.19496 Data1 FF FF FF C0 00 00 00 00 01 FF FC 00 00 00
......
3 0.54696 Data1 00 1F FF FF FF 80 00 FF FF FF FF FF F8 00
20 Saving and Loading Data
