SDTV Example
524 525
(1) (2) (3) (4) (5) (6) (7) 8 9 10 11 12 13 14
Line number
2207 2208
526
568
2209 2251
The line numbers inside parentheses
cannot be specified.
43
30H
42H
6H
6H
HDTV Example
• Example for 1080/60i, 1080/50i, or 1080/24sF
The following line numbers are those when the field number is set to 1
(if the field number is set to 2, the numbers are assigned sequentially by setting 565 to 2).
1120 1125
(1) 2 5 6 7 41
5H 5H 35H
517H
45H
557 562 563 564 565 568 569 603
5H 5H 34H
518H45H
1/2H
1/2H
Field 1
Field 2
Line number
2245 2250
1126 1127 1130 1131 1132 1166
2251
1682
1687 1688 1169 1170 1173 1174 1728
The line numbers inside parentheses
cannot be specified.
• 720/60p Example
750
(1) 2 3 4 5 6 7
5H 5H 20H
30H
Line number
2250
751 752 753 754 755 756 757
2251
The line numbers inside parentheses
cannot be specified.
• Example for 1080/25p, 1080/24p, or 1080/60p
1125
(1) 2 3 4 5 6 7
5H 5H
35H
45H
Line number
2250
1126 1127 1128 1129 1130 1131 1132
2251
The line numbers inside parentheses
cannot be specified.
User Defined (Userdef TV)
Define appropriate values for definition, horizontal sync frequency, sync guard frequency, etc.
Trigger Source (Source), Polarity (Polarity), Trigger Level (Level)
Line Number (Line), Field Number (Field), Frame Skip (Frame Skip)
These items are the same as when a specific broadcasting system is specified.
4 Triggering
