YOKOGAWA MX100 User Manual

4-23
IM MX100-01E
Specification
3
2
1
4
5
Index
Setting Value of Span and Preset, and Specified Value of Command Output
Analog output setting value Command output specified value
span and preset value (count)
Voltage Current
-11.000 V 0.000 mA -22000
-10.000 V 0.000 mA -20000
0.000 V 0.000 mA 0
1.000 V 4.000 mA 2000
5.000 V 20.000 mA 10000
5.500 V 22.000 mA 11000
10.000 V 25.000 mA* 20000
11.000 V 25.000 mA* 22000
* Value in calculation. Actually, the value is clipped at approximately 22 mA.
Output Span Setting
Span setting data when setting transmission output
V mode
Output voltage [V] -10.000 10.000
PC data* - 10000 10000
* PC data refers to internal data between the PC and MX100 main unit, and on the PC software, the
output value is expressed in the same manner with 3 digits after the decimal point.
mA mode
Output voltage [mA] 0.000 20.000
PC data* 0 20000
* PC data refers to internal data between the PC and MX100 main unit, and on the PC software, the
output value is expressed in the same manner with 3 digits after the decimal point.
Limit value of V mode and mA mode
Mode Output Setting span Setting span Output
lower limit
*
lower limit upper limit upper limit
**
V mode -11[V] -10[V] +10[V] +11[V]
mA mode 0[mA] 0[mA] 20[mA] 22[mA]
* -OVER, preset value
** +OVER, preset value
Handling Abnormal Data
Types of Abnormal Data Output Values
Output data upon startup Preset value or previously held value can be selected
Data upon error occurrence Preset value or previously held value can be selected
+OVER 5%ofoutputFullSpan 
-OVER -5%ofoutputFullSpan
±OVERdetermination
 Forcommandoutput,±OVERdeterminationisperformedonthePC,andifthelimit
value is exceeded, it is clipped at that limit value. For transmission output within the
same unit, OVER is determined by the MX100 main unit.
±OVERconditions
• Whentheinputchannelis±OVERinthecaseoftransmissionoutput
• When outside the range of ±5%ofoutputFullSpan
• When outside the range of voltge -11 V to +11 V, or current 0 mA to 22 mA (accuracy
assured at 1 mA or more)
4.9 8-CH, Medium-Speed Analog Output Module Specifications
