4.2 Main Module Specifications
Measurement
Style number: S2
Meas. range and accuracy:
See the measurement range and accuracy given in the
specicationsofeachinputmodule.
Max. number of inputs: 60 (however a maximum of six modules can be controlled)
Meas. interval: Select from 10, 50, 100, 200, 500 ms, 1, 2, 5, 10, 20, 30, or 60 s.
 Uptothreeintervalsdenedfortheinputmodulescanbeset
(multi-interval)
Synch. between modules:
Synchronized within the same sampling interval (in the same unit)
Synch. between channels:
4-CH, High-Speed Universal Module and Digital Input Module:
synchronized between channels. 10-CH, Medium-Speed Universal
Input Module, Six-Channel Medium-Speed Four-Wire RTD Resistance
Input Module, and the 4-CH, High-Speed Digital Input Module: due to
the scanner type, not synchronized between channels
Timesetting: ConguredbasedonthetimeinformationsentfromthePCatthe
start of measurement
Filterfunction: First-orderlaglter,applicablemeasurementtypes:
DC voltage, TC, RTD, strain, and resistance. You can select a
timeconstant(timeuntil63.2%oftheoutputvalueisreached)
corresponding to the sampling interval indicated in the table below.
Time constant = measurement interval × N (where N = 5, 10, 20,
25, 40, 50, or 100)
Measurement Interval (s) Selectable Time Constants (s)
n=5 n=10 n=20 n=25 n=40 n=50 n=100
0.01 0.05 0.1 0.2 0.25 0.4 0.5 1
0.05 0.25 0.5 1 1.25 2 2.5 5
0.1 0.5 1 2 2.5 4 5 10
0.2 1 2 4 5 8 10 20
0.5 2.5 5 10 12.5 20 25 50
1 5 10 20 25 40 50 100
2 10 20 40 50 80 100 200
5 25 50 100 125 200 250 500
10 50 100 200 250 400 500 1000
20 100 200 400 500 800 1000 2000
30 150 300 600 750 1200 1500 3000
60 300 600 1200 1500 2400 3000 6000
Computation
Computation performed on the main module
Difference comp. between channels:
Difference computation between arbitrary channels (DC voltage,
TC, RTD, DI, strain, resistance, and scaling)
Linear scaling: Possible scaling ranges: DC voltage, TC, RTD, DI, strain, and
resistance
Scaling range: -30000 to 30000
Scaling display range: -32000 to 32000
Decimal point position: Arbitrary
