3.5 MX100 Maintenance and Test Using
Communication Commands
The MX100 maintenance/test function is used by a network administrator to check
the communication status of the MX100. Maintenance and Test of the MX100 using
communication commands can be carried out by connecting the main module and a PC
using an Ethernet cable, and using a terminal emulator such as Telnet on the PC. The
communication method is a command and response type (a command is sent from the
PC to the MX100 and a response is returned from the MX100 to the PC). Only a single
PC can connect to a single MX100.
Connecting the Main Module and the PC
See “Connection Procedure” in section 2.6, “Connecting the Ethernet Cable.”
Setting the Terminal Emulator
When carrying out maintenance and test of the MX100 using communication commands,
set the terminal emulator as indicated below. Specify the IP address of the MX100 and a
port number of 34317 for the destination of the terminal emulator.
• Local echo: ON
• Line feed code of the transmit data: CR+LF
List of Maintenance/Test Commands
Command Name Function
con Outputs TCP connection information.
eth Outputs statistical information of Ethernet (data link layer).
help Outputs command help.
net Outputs other network information.
quit Quits maintenance/test (drops the connection).
Specifications of the Maintenance/Test Port
Port number 34317/tcp
Transfer data ASCII code
Line feed code (command) CR+LF or LF
Line feed code (response) CR+LF
Receive buffer 128 B
Transmit buffer 8192 B
Connection timeout 3 min. (fixed*)
Maximum number of simultaneous connections 1
* You cannot change the connection timeout setting.
