1.5 Functions of the 6-CH, Medium-Speed Four-Wire RTD Resistance Input Module
The following inputs can be used on MXLOGGER or the MX100/DARWIN API (sold
separately). These inputs cannot be used on the MX100 Standard Software.
Input
DC voltage
60mV (high resolution)
1V
6V (high resolution)
Cu10 at 20°C
alpha = 0.00392
Cu10 at 20°C
alpha = 0.00393
Cu25 at 0°C
alpha = 0.00425
Cu53 at 0°C
alpha = 0.00426035
Cu100 at 0°C
alpha = 0.00425
Pt25(JPt100*1/4)
Cu10 GE (high resolution)
Cu10 L&N (high resolution)
Cu10 WEED (high resolution)
Cu10 BAILEY (high resolution)
0.000 to 60.000 mV
-1.0000 to 1.0000 V
0.0000 to 6.0000 V
-200.0 to 300.0°C
-200.0 to 300.0°C
-200.0 to 300.0°C
-50.0 to 150.0°C
-50.0 to 150.0°C
-200.0 to 550.0°C
-200.0 to 300.0°C
-200.0 to 300.0°C
-200.0 to 300.0°C
-200.0 to 300.0°C
Rated Measurement Range
RTD
(Measurement current:1 mA)
Measurement Range Type
Measurement Interval, Integration Time, and Filter
The table below shows the available measurement intervals. The module is equipped
with an integrating A/D converter. The selectable integration time varies depending on
the measurement interval as shown in the table below. For details about the relationship
between noise and integration time, see section 2.7, “Measures against Noise on the
MX100 Data Acquisition Unit.” In addition, the type of noise rejection filter switches as
shown in the table below.
600 Hz and its integer multiples*
60 Hz and its integer multiples
50 Hz and its integer multiples
Automatically detects the power supply frequency and
set 16.67 or 20 ms
50 Hz and 60 Hz and their integer multiples
10 Hz and its integer multiples
Fc = 5-Hz low-pass filter
100 ms
200 ms
500 ms
1 s
2 s
5 s
10, 20, 30, 60 s
1.67 ms
16.67 ms
20 ms
Auto
36.67 ms
100 ms
200 ms
Rectangular
Trapezoidal
Rectangular
Cos
* When the measurement interval is 100 ms or 200 ms, measured values may fluctuate especially for tempera-
ture and 20 Ω measuments since power supply frequency noise is not eliminated. In such cases, set the
measurement interval to 500 ms or more.
Measurement
Interval
Integration
Time
Filter Rejected Noise and Notes
Measurement Synchronization
The module is equipped with a single A/D converter, and measurement is made
sequentially. Therefore, measurements of each channel are not synchronized.
Common Mode Voltage
The common mode voltage between channels in a single module when applied
continuously is 120 VACrms, and the resistance for RTD is 50 VACrms.
The common mode voltage between modules and between a module and earth is 600
VACrms when the signal is applied continuously.
