Module Errors
The left and right digits of the 7-segment LED display “E” and an error code,
respectively. The LED illuminates. In the case of module errors, the error number and the
corresponding module number are displayed alternately as shown in the figure below.
Error number Module number
Display Probable Cause Corrective Action Ref. Page
E0 Range information error. Servicing required. -
E1 Calibration value error. Check the module’s installation status, then recalibrate *
the module. If the error occurs even after recalibrating,
servicing is required.
E2 Calibration reference voltage value Check whether the correct calibration reference voltage is *
is not correct (during calibration). being applied or whether the channel to which the
voltage is applied is correct.
E3 Error in writing the calibration value. Servicing required. -
E4 The installed module cannot be used. Replace the module with one that can be used. -
E5 Initial balancing (Initial unbalance value Check the module’s installation status, then
adjustment) Error perform initial balancing again. If the error occurs -
even after recalibrating, servicing is required.
* See the MX100 Standard Software User’s Manual.
Media-Related Errors
The left and right digits of the 7-segment LED display “P” and an error code, respectively.
The LED blinks. The error code is saved to the log file (see page 1-11).
Display Probable Cause Corrective Action Ref. Page
P0 Manipulated the CF card while it was Do not manipulate the CF card while it is being 2-24
being accessed. accessed.
P1 CF card error. The CF card may not be formatted or may be damaged. -
Check the CF card.
P2 The CF card was not formatted correctly. Insert the CF card into the CF card slot and format the card *
again, or replace with another CF card.
P3 Not enough free space on the CF card. Delete unneeded data to increase the free space, *
or replace with another CF card.
P4 The number of files saved on the Delete unneeded files to decrease the number of files, or *
CF card exceeded 512. replace with another CF card.
P5 Overwrite error in the data The time needed to store the file must be reduced. *
storage buffer Delete unneeded data to increase the free space, or format
the CF card.
If you are using a software application through the MX100/
DARWIN API, the timeout setting may not be appropriate.
If so, change the value to an appropriate value.
* See the MX100 Standard Software User’s Manual.
Communication Errors
The left and right digits of the 7-segment LED display “C” and an error code, respectively.
The LED blinks.
Display Probable Cause Corrective Action Ref. Page
C1 Multiple connection error. Disconnect the current connection and reconnect. *
However, this error may also appear when the Ethernet
cable is removed and inserted again.
* See the MX100 Standard Software User
’
s Manual.
3.1 Error Display on the 7-Segment LED and Corrective Actions
To Next Page
