YOKOGAWA MX100 User Manual

4-1
IM MX100-01E
Specification
3
2
1
4
5
Index
Chapter 4 Specification
4.1 Common Specifications
Standard operating conditions
Operating temperature range: 0 to 50°C
Ooperationhumidityrange: 20to80%RHfor0to40°C
  10to50%RHfor40to50°C
Rated supply voltage: AC power supply, 100 to 240 VAC
Supply voltage range used: AC power supply, 90 to 250 VAC
Powersupplyfrequency: 50Hz±2%,60Hz±2%
Power consumption: Up to approximately 70 VA maximum when six modules
are used
Vibration: 10 to 60 Hz 0.2m/s
2
or less
Shock: Not allowed
Magneticeld:  400A/morless(50/60Hz)
Position: Upright and horizontal to ground
Structure: Not explosion-proof
Usage location: Indoors
Operating altitude: 2000 m or less
Installation category: II (per CSA22.2 No. 61010-1)
Pollution degree: 2 (per IEC
61010-1 CSA22.2 No. 61010-1)
Transport and Storage Conditions
Environmental conditions during transport and storage
Storage ambient temperature: -25
to 60°C
Storageambienthumidity: 5%to95%RH(nocondensation)
Vibration: 10 to 60 Hz 4.9m/s
2
or less
Shock: 392 m/s
2
or less (packaged condition)
Mechanical Specifications
External dimensions: Approx. 442 × 131 × 159 mm (when six slots are attached)
Weight: Approx. 4.1 kg (maximum total weight)
Installationmethod:  Desktoporoor,panelmount,orattachedtoaDINrail
Material: Steel plate, aluminum die-cast, molded plastic resin
Supported Standards
CSA: Conforms to CSA22.2 No. 61010-1, installation category
(overvoltage category) II, pollution degree 2
UL: Conforms to UL61010B-1 (CSA NRTL/C)
CE: EMC directives; EN61326
EN61000-3-2
EN61000-3-3
Low voltage directive: EN61010-1; measurement category II,
pollution degree 2
C-Tick: Conforms to AS/NZS CISPR11 Class A Group1
InstallationcategoryII:Anindexfordeningtransientovervoltages(includestherated
impulse withstand voltage, and applies to electrical equipment
suppliedwithpowerfromxedinstallationssuchasdistribution
boards).
Pollution degree 2: Indicates the degree of adherence by a solid, liquid, or vapor that
reduces the withstand voltage or surface resistance (applies only
to normal indoor atmospheres (with non-conductive pollution).
Measurement category II:
Applies to electrical instruments that are powered by wall outlets
andotherxedinstallationsthatarewiredtodistributionboards,
or measurements of such wires.
