1.10 Operation of the 8-CH Medium-Speed Analog Output Module and the 8-CH Medium Speed PWM Output Module
Output When Abnormal, or after Recovery from Abnormality
Output Operation during Abnormality (by Module)
Abnormal Abnrml Abnormal Status Output Operation
Module Display
Main Module b[SQR]
*
System error Operation upon startup
bF Dip switches
F0 ROM error
F1 SRAM error Operation upon startup
F2 EEPROM error
F3 Battery error
F4 Ethernet error
P[SQR]
*
CF card related error No effect (normal operation)
None Communication timeout error Transmission within units: no effect
(normal operation)
Transmission between units/manual
output/pattern output: operation
when error generated
C1 Comm multiple connect error No effect (normal operation per the
previously connected device)
Output Modules E0 Range information error Operation
upon startup or when
output value uncertain
E1 Calibration value error
E2 Error during calibration Internal communication error
occurs, resulting in an error
recovery event. If the error
recovery time is 10 s or more,
output is performed per the
operation upon error occurrence,
and then output is executed per the
operation upon startup.
E3 Error in writing the calibration value.
E4 Unusable modules Operation upon startup or when
output value uncertain
Input Modules E0 Range information error Operation upon errors occurrence
(except for transmission within
E1 Calibration value error units, since the transmission
E4 Unusable modules source input channel is illegal)
 E5 Initialbalanceerror Noeffect(±Overislikely)
* [SQR] is a placeholder for the number corresponding to the error.
