4-19
IM MX100-01E
Specification
3
2
1
4
5
Index
4.7 4-CH, Medium-Speed Strain Input Module
Specifications
Style number: S2
Number of inputs: 4
Input type: Strain gauge or strain gauge type sensors (static strain)
Input method: Floating balanced input, islated between channels (NDIS is non-
isolated)
Measurement range and accuracy:
The accuracy applies to standard operating conditions:
Ambienttemp:23±2°C,ambienthumidity:55±10%RH,supplyvoltage:
90to250VAC,powerfrequency:50/60Hz±1%,warm-uptime:at
least 30 minutes, without adverse conditions such as vibrations.
One-Gauge Method Conversion Value
1 µStrain
2 µStrain
10 µStrain
0.1 µStrain
1 µStrain
10 µStrain
2% of range
1% of range
1% of range
0.5% of range
0.3% of range
0.3% of range
*1
*2
2000 µStrain
20000 µStrain
200000 µStrain
Strain
2000.0 µStrain
20000 µStrain
200000 µStrain
*1 Display resolution is 0.1 µStrain
*2 Display resolution is 1 µStrain
Measurement
Range
Type
Input
Rated
Measurement
Range
Resolution Resolution
Integration time:
16.67 ms or more
Integration time:
1.67 ms or more
Measurement Accuracy Measurement Accuracy
ADresolution: Equivalentto±20000FSdisplay
However, excludes 1.67 ms integration time
AD integration time:
Measurement
Interval
1.67 ms
16.67 ms
20 ms
Auto
36.67 ms
100 ms
200 ms
Integration
Time
Filter
Rejected Noise and Notes
Rectangular
100 ms
200 ms
500 ms
1 s
2 s
5, 10, 20, 30, 60 s
Trapezoidal
Rectangular
Cos
600 Hz and its integer multiples*
60 Hz and its integer multiples
50 Hz and its integer multiples
Automatically detects the power supply frequency and set 16.67 or 20 ms
50 Hz, 60 Hz and their integer multiples
10 Hz and its integer multiples
Fc = 5-Hz low-pass filter
* When the measurement interval is 100 ms, measured values may fluctuate since power supply frequency
noise is not rejected.
In such cases, set the measurement interval to 200 ms or more.
Gauge connection method:
1-gauge (2 or 3 wire systems), opposing 2-gauge, adjacent 2- or
4-gauge
With clamp terminals, set on a channel basis with switches
Applicable gauge resistance:
100-1000Ω
Builtinresistanceof120Ωfor-B12,and350Ωfor-B35.
Bridgevoltage: Fixedat2VDC,accuracy±5%,compensatedwithinternalCal
Applicable gauge factor:
Fixed at 2.0. Gauge factor can be compensated with the scaling function.
Balance adjustment: Automatic, digital calculation methods
Balance adjustment range:
±10000µstrain(1-gaugemethodconversion)
Balance adjustment accuracy:
The measurement accuracy or less:
Resistanceaccuracyforbridge:±0.01%
±5ppm/°C
Inputresistance: 1MΩormore
Allowablewiringresistance:100Ωorless
Effectofwiringresistance:NDIS50ppmofrdg/Ω(whenusingremotesensingwire).
Does not compensate for clamp wiring resistance. Depends on
the gauge resistance.
