1.3 Functions of the 4-CH, High-Speed Universal
Input Module
This module is equipped with four inputs and measures DC voltage, TC, RTD, and digital
input (DI) at a minimum measurement interval of 10 ms (the minimum interval is 50 ms if
the input type is thermocouple or three-wire RTD).
Input terminal (clamp terminal)
Terminal cover
Input Type and Measurement Range
The following measurements are possible.
Input
DC voltage
20 mV
60 mV
200 mV
2 V
6 V
20 V
100 V
R
S
B
K
E
J
T
L
U
N
W
KPvsAu7Fe
Pt100
JPt100
Pt100 (high resolution)
JPt100 (high resolution)
Ni100 SAMA
Ni100 DIN
Ni120
Pt100
JPt100
Pt100 (high resolution)
JPt100 (high resolution)
Pt50
Cu10 GE
Cu10 L&N
Cu10 WEED
Cu10 BAILEY
J263B
Level
Contact input
-20.000 to 20.000mV
-60.00 to 60.00mV
-200.00 to 200.00mV
-2.0000 to 2.0000V
-6.000 to 6.000V
-20.000 to 20.000V
-100.00 to 100.00V
0.0 to 1760.0°C
0.0 to 1820.0°C
-200.0 to 1370.0°C
-200.0 to 800.0°C
-200.0 to 1100.0°C
-200.0 to 400.0°C
-200.0 to 900.0°C
-200.0 to 400.0°C
0.0 to 1300.0°C
0.0 to 2315.0°C
0.0 to 300.0K
-200.0 to 600.0°C
-200.0 to 550.0°C
-140.00 to 150.00°C
-140.00 to 150.00°C
-200.0 to 250.0°C
-60.0 to 180.0°C
-70.0 to 200.0°C
-200.0 to 250.0°C
-200.0 to 250.0°C
-140.00 to 150.00°C
-140.00 to 150.00°C
-200.0 to 550.0°C
-200.0 to 300.0°C
-200.0 to 300.0°C
-200.0 to 300.0°C
-200.0 to 300.0°C
0.0 to 300.0K
Vth = 2.4V
ON: 100 Ω or less, OFF: 10 kΩ or more
Rated Measurement Range
DI
RTD
(Measurement current:1 mA)
Thermocouple
RTD
(Measurement current: 2 mA)
Measurement Range Type
