YOKOGAWA MX100 User Manual

i
IM MX100-01E
Foreword
Thank you for purchasing the MX100 Data Acquisition Unit. This user’s manual contains
useful information about the instrument’s functions, installation and wiring procedures,
operating procedures, and handling precautions. To ensure correct use, please read
this manual thoroughly before beginning operation. The four manuals below are also
provided in addition to this manual. Read them along with this manual. As with this
manual, the MX100 Standard Software User’s Manual (IM MX180-01E) is included in the
accompanying CD-ROM.
Manual Title Manual No. Description
MX100 Data Acquisition IM MX100-02E Describes concisely the handling of the
Unit Operation Guide MX100 Data Acquisition Unit and the basic
operations of the MX100 Standard Software.
Precautions on the Use of IM MX100-71E Summarizes the precautions regarding the use
the MX100 Data Acquisition Unit of the MX100 Data Acquisition Unit.
MX100 Data Acquisition IM MX100-72E Describes concisely the installation procedures
Unit Installation and and wiring procedures of the MX100 Data
Connection Guide Acquisition Unit.
MX100 Standard Software IM MX180-01E Describes the functions and operations of the
User’s Manual MX100 Standard Software that comes
standard with the MX100 main module.
Notes
When configuring an MX100 system, you must match the versions of the instruments
used in the system as indicated by the hardware style number and software release
number, according to the conditions that follow.
• The style numbers of any input/output modules must be less than or equal to that
of the main unit to which they are connected.
• The release number of the software must be greater than or equal to that of the
MX100 main unit. Certain functions may become disabled on instruments or
software for which these conditions are not met, or the instruments or software may
not be able to be incorporated into the system.
This manual describes the MX100 Data Acquisition Unit, style number “S2.” Check the
style number on the name plate of the main module (see page iv for the location of the
name plate).
• The contents of this manual are subject to change without prior notice as a result of
continuing improvements to the instrument’s performance and functions.
• Every effort has been made in the preparation of this manual to ensure the accuracy
of its contents. However, should you have any questions or find any errors, please
contact your nearest YOKOGAWA representative, dealer, or sales office.
• Copying or reproducing all or any part of the contents of this manual without the
permission of Yokogawa Electric Corporation is strictly prohibited.
• The TCP/IP software of this product and the document concerning the TCP/IP
software have been developed/created by YOKOGAWA based on the BSD Networking
Software, Release 1 that has been licensed from the University of California at
Berkeley.
Trademarks
• Microsoft, MS-DOS, Windows, and Windows NT are either registered trademarks or
trademarks of Microsoft Corporation in the United States and/or other countries.
• Adobe and Acrobat are trademarks of Adobe Systems incorporated.
• Company and product names that appear in this manual are trademarks or registered
trademarks of their respective holders.
Revisions
1st Edition: May, 2003
2nd Edition: November, 2004
3rd Edition: June, 2006
3rd Edition : June 2006 (YK)
All Rights Reserved, Copyright © 2003 Yokogawa Electric Corporation
