YOKOGAWA MX100 User Manual

1-27
IM MX100-01E
Explanation of Functions
3
2
1
4
5
Index
1.10 Operation of the 8-CH Medium-Speed Analog Output Module and the 8-CH Medium Speed PWM Output Module
Output Operation per Setting Changes (Common)
Setting Changes (Contents) Output Operation
Changestosettingsforop. Holdprev.val.→presetval. Outputsapresetvaluethenext
time upon startup the power is
turned ON
 Presetval.→holdprev.val. Thelastoutputvaluefromthe
previous operation is held for the
next time the power is turned ON
(outputs the output value active when
the power was last turned OFF
during the previous session)
Changestosettingsforop. Holdprev.val.→presetval. Outputsapresetvaluethenext
time when error occurs an error
occurs
 Presetval→holdprev.val. Holdsthelastoutputvalueactive
before an error occurs even when the
next error occurs.
Changes to the preset value setting* No change (as above)
OutputchsettingchangedfromEnabled→Disabled Holdstheoutputval.(lastoutputval.)
* Changes are also applied to inactive channels.
Output Operation through Setting Changes (Individually by Output Setting)
Output Setting Changes (Contents) Output Operation
Setting
Trans.output Rangesettingchng. AO:V↔mA  Outputvalueheld
withinunits  PWM:1ms↔10msorinterval (untilnextoutputevent)
 Op.settingchng. Trans.withinunits→Trans.between  
units
  Trans.withinunits→manualoutput
  Trans.withinunits→patternoutput
Trans.output Rangesettingchng. AO:V↔mA  Outputvalueheld
betweenunits PWM:1ms↔10msorinterval (untilnextoutputevent)
(cmd.output) Op.settingchng. Trans.betweenunits→trans.within   
units
  Trans.betweenunits→manualoutput
  Trans.betweenunits→patternoutput
ManualoutputRangesettingchng. AO:V↔mA  Outputvalueheld
(cmd.output)  PWM:1ms↔10msorinterval (untilnextoutputevent)
 Op.settingchng. Manualoutput→trans.withinunits
  Manualoutput→trans.betweenunits
  Manualoutput→patternoutput
Span setting changes
PatternoutputRangesettingchng. AO:V↔mA  Outputvalueheld
(cmd.output)  PWM:1ms↔10msorinterval (untilnextoutputevent)
 Op.settingchanges Patternoutput→trans.withinunits
  Patternoutput→trans.betweenunits
  Patternoutput→manualoutput
Span setting changes
