YOKOGAWA MX100 User Manual

1-31
IM MX100-01E
Explanation of Functions
3
2
1
4
5
Index
1.10 Operation of the 8-CH Medium-Speed Analog Output Module and the 8-CH Medium Speed PWM Output Module
Output Operation after Recovery from Abnormality (by Output Setting)
Output Setting Abnormality Recovery Output Operation
Trans.output Referencedinputmodulerecovers Operationuponerrors→ 
within units (removed input modules are inserted) tansmission output
Referenced input channel changed
from Skip to measurement range
Referenced input channel is Invalid
Recovers to normal from (math error
in difference computation)
Recover after communication timeout No effect
Recover after internal comm error If the error recovery time is 10 s or
more; operation upon error
  occurrence→operationupon
startup -> transmission output
If the error recovery time is within
  10s;operationuponstartup→
transmission output
CPU abnormality (does not recover) Operation upon errors
Trans. output Referenced input module recovers Operation upon errors (per PC
betweenunits (removedinputmodulesareinserted) software→commandoutput
*
(cmd. output) Referenced input channel changed
from Skip to measurement range.
Referenced channel is invalid; recovers
to normal value from (math error).
 Recoveraftercommunicationtimeout Operationuponerrors→ 
command output
*
Recover after internal comm error If the error recovery time is 10 s or
more; operation upon error
  occurrence→operationupon
  startup→commandoutput
*
If the error recovery time is within
  10s,Operationuponstartup→
command output
*
CPU abnormality (does not recover) Operation upon errors
Manualoutput Recoveraftercommunicationtimeout. Operationuponerrors→command
(cmd. output) output
*
Recover after internal comm error If the error recovery time is 10 s or
more, Operation upon errors
  →operationuponstartup→command
output
*
If the error recovery time is within
  10s,Operationuponstartup→
command output
*
CPU abnormality (does not recover) Operation upon errors
Patternoutput Recoveraftercommunicationtimeout Operationuponerrors→command
(cmd. output) output
*
Recover after internal comm error If the error recovery time is 10 s or
  more;operationerroroccurrence→
  operationuponstartup→command
output
*
If the error recovery time is within
  10s,Operationuponstartup→
command output
*
CPU abnormality (does not recover) Operation upon errors
* Executes the command output from the PC software after recovery from errors.
