The MX100 can be detected using the Search button, but connection fails.
Probable Cause Corrective Action Ref. Page
The IP address is set to the default Set the correct IP address. *
value. The default value cannot be
used to make the connection.
There is a problem in the network Check that the IP address, subnet mask, and default gateway *
configuration. settings of the PC and the MX100 settings are correct.
Follow the rules for I/O on the Check the PC software release number and main unit style i
PC software and MX100 main unit. number before upgrading the version.
[PCsoftwarereleaseno.]≥[mainunitstyleno.]≥[modulestyleno.]
* See the MX100 Standard Software User’s Manual.
The Calibrator cannot connect to the MX100.
Probable Cause Corrective Action Ref. Page
Attempting to make multiple Close all other software programs such as the MX100 *
connections. Another software Standard Software.
program such as the MX100
Standard Software is already
connected.
The style no.’s of the MX100 and Check the PC software release number and main unit style i
modules do not match. number before upgrading the version.
[PCsoftwarereleaseno.]≥[mainunitstyleno.]≥[modulestyleno.]
* See the MX100 Standard Software User’s Manual.
Four-wire RTD resistance input module recognized as a 10-CH universal input module
Probable Cause Corrective Action Ref. Page
The MX100 main unit style number Upgrade to a later style. **
remains at 1.
** See the MX100 Upgrade Kit user’s manual (IM MX100-77).
The connected input/output module is not detected.
Probable Cause Corrective Action Ref. Page
Module connection or module Turn OFF the power. Detach the input/output module once 2-4, 2-17
startup error. and attach it again.
Attached the module while the
power was ON.
Carried out an incorrect calibration. Recalibrate. *
* See the MX100 Standard Software User’s Manual.
3.2 Troubleshooting
To Next Page
