YOKOGAWA MX100 User Manual

4-11
IM MX100-01E
Specification
3
2
1
4
5
Index
Effects of Operating Conditions
Thespecicationsbelowapplywhentheintegrationtimeis16.67msormore.
Warm-up time: At least 30 minutes after power-up
Effects of ambient temperature:
The effect received by changes in 10°C increments of the ambient
temperatureis:±(0.05%ofrdg+0.05%ofrange)orless
 However,Cu10Ω:±(0.2%ofrange+1digit)
Effectsofpoweructuation:      
MeetstheaccuracyspecicationsforACpowersupplyinthe
range 90 to 132 V and 180 to 250 V
Effectsofmagneticeld:       
TheuctuationinexternalmagneticeldsforAC(50/60Hz)400
A/mis±(0.1%ofrdg+10digits)orless
Effects from the signal source resistance: Effects on DC voltage and thermocouple
fromauctuationof1kΩinthesignalsourceresistance
  DCvoltage: 1Vrangeorless±10mVorless
   2Vrangeorhigher±0.15%ofrdgorless
  Thermocouple:±10mVorless
   However,±150µVorlessforburnoutsetting.
  RTD: Fluctuationdueto10Ωchangepercable(same
resistanceforthethreewires);100Ωsystem:
   ±0.1°Corless,systemsotherthan100Ω:±1.0
°C or less. Fluctuation due to a difference in the
resistancebetweenleadwiresof40mΩ(maximum
difference among three wires) is approximately 0.1°C
(for Pt100)
Effect of position: Horizontal with the feet at the bottom is the rule.
Effectsofvibration: Theuctuationthatresultsbyapplyingasinusoidalvibration
along all three axis at a frequency between 10 to 60 Hz and an
acceleration of 0.2 m/s
2
is±(0.1%ofrdg+1digit)orless
External Dimensions
Unit: mm
150.857
131
If not specified, the tolerance is ±3%.However,incasesoflessthan10mm,the
tolerance is ±0.3 mm.
4.4 4-CH, High-Speed Universal Input Module Specifications
