24-1
SM80B22M02E
Chapter 24 Alarm threshold of Rudder Erroneous
① Set the detection limit angle (deviation value)
② Set the detection time
１． Select the item
（１）Press the
ENTER
ENTERENTER
ENTER
key after displayed "
Option Set 5
…
"(PT500A)"
or
"
Option Set 6
…
"(PT500D･SUBAUTO) on the data display.
Data display become under setting mode.
（２）Change the setting item by using the
△
△△
△
+
++
+
or
▽
▽▽
▽
-
--
-
Key
①⇔②⇔③⇔④⇔①
①
Press
ENTER
ENTERENTER
ENTER
key to set the setting item..
２． Set the detection limit angle
（１）Press the
ENTER
ENTERENTER
ENTER
key after displayed "
Limit Angle= ##ˆ
""
on the data display.
Data display become under setting mode.
Setting range: from 0 to 20
(Initial value is set 5 degree)
If you set the 0 , it means no monitor of rudder erroneous.
（２）Press
△
△△
△
+
++
+
or
▽
▽▽
▽
-
--
-
key to select the limit angle value .
Press
ENTER
ENTERENTER
ENTER
key to set the limit angle value.
To Next Page
