YOKOGAWA PT500 User Manual

5-1
SM80B22M02E
Chapter 5 DAC Output
Output the rudder value based on the DAC and display the Rudder feedback angle value at every 0.5
second. Output value can select the Rudder angle (
Ｐ４５～Ｓ４５） or DAC value （０～ FFF ） .
The actual control routine is bypassed under this operation.
（１） Select the " MAINTENANCE 4 … " mode on the data display. Then press ENTER
ENTERENTER
ENTER key.
Rudder output become Mid ship position.
The data display become under setting mode.
（２） Press △
△△
△ +
++
+ or ▽
▽▽
▽ -
--
- key to alter the cursor position.
①⇔②⇔③⇔①
①
← DAC value input
②
← Rudder value
③
（３） Select the AUTO RUDDER OUT of DAC value input, then press the ENTER
ENTERENTER
ENTER key.
The data display become under setting mode.
← Cursor position is inputting point
（４） Press △
△△
△ +
++
+ or ▽
▽▽
▽ -
--
- key to alter the cursor position. Then change the address by turning the
course setting dial .
Turn to the clockwise the course setting dial, data is increased . Turn to the counterclockwise it ,data is
decreased. (HEX data is from o to F.)
← Cursor position is inputting point
（５） Press ENTER
ENTERENTER
ENTER key. Rudder order from the DAC value shall be supplied.
← Cursor position is inputting point
Rudder feedback
angle
Rudder angle （Ｐ４５～Ｓ４５）
ＤＡＣ value （０ｈ～ＦＦＦｈ）
AUTO RUDDER OUT
=[800] 0 a###.#
AUTO RUDDER OUT
=[800] 0 a###.#
AUTO RUDDER OUT
= 800[ 0]S###.#
AUTO RUDDER OUT
= <EXIT>
AUTO RUDDER OUT
<[800] 0 a###.#
AUTO RUDDER OUT
<[CB0] 0 a###.#
AUTO RUDDER OUT
=[CB0]P30 a###.#
