３．Selection of the maintenance mode
（１）Display the
"MAINTENACE 1 … "on the data display then Press the ENTER
ENTERENTER
ENTER key.
The data display is displayed I/F SET-UP mode.
（２）You can change the each maintenance item by pressing the △
△△
△ +
++
+ or ▽
▽▽
▽ -
--
- key.
ＰＴ５００Ａ：
①⇔②⇔③⇔④⇔⑤⇔⑥⇔⑦⇔⑧⇔⑨⇔⑩⇔⑪⇔⑫⇔⑬⇔⑭⇔⑮⇔⑯⇔⑰⇔⑱⇔⑲⇔①
① ⑪
② ⑫
③ ⑬
④ ⑭
⑤ ⑮
⑥ ⑯
⑦ ⑰
⑧ ⑱
⑨ ⑲
⑩
Press ENTER
ENTERENTER
ENTER key after you selected the maintenance number. Then the maintenance function become valid
mode .
MAINTENANCE 19
…
MAINTENANCE OFF
MAINTENANCE 18
…
Special Data
MAINTENANCE 17
…
Option Set
MAINTENANCE 16
…
LINK-SLAVE DATA
MAINTENANCE 15
…
OVERRIDE COURSE
MAINTENANCE 14
…
KEY CLICK SW
MAINTENANCE 8
…
PROGRAM VERSION
MAINTENANCE 7
…
ADC POINT DISP
MAINTENANCE 6
…
CDV OUT
MAINTENANCE 5
…
RDA OUT
MAINTENANCE 4
…
AUTO RUDDER OUT
MAINTENANCE 13
…
BARGRAPH SW
MAINTENANCE 12
…
OFFCRS ALARM SW
MAINTENANCE 11
…
IDENT. DISP
MAINTENANCE 3
…
MEM ACCESSS-FLX
MAINTENANCE 2
…
MEM ACCESSS-FIX
MAINTENANCE 1
…
I/F SET-UP
MAINTENAN
CE 9
…
PROG.COLD START
MAINTENANCE 10
…
SHIP PARA. CALC
