YOKOGAWA PT500 User Manual

22-4
SM80B22M02E
４．Lower limit of High speed area（Ｓ３）
（１） When you are displayed ” Speed-H1= ## Kt “ on the data display ,then press ENTER
ENTERENTER
ENTER key.
The data display become under setting mode.
Setting range: from 3 to 30
（２） Press △
△△
△ +
++
+ or ▽
▽▽
▽ -
--
- key to alter the value of Lower limit of High speed area.
Press
ENTER
ENTERENTER
ENTER key to set the value of Lower limit.
The display of
Lower limit of High speed area is changed 30 ⇔ 31 ･････ 60 ⇔ 30 .
５．Upper limit of Low speed area （Ｓ4）
（１） When you are displayed ” Speed-H2= ## Kt “ on the data display ,then press ENTER
ENTERENTER
ENTER key.
The data display become under setting mode.
Setting range: from 3 to 30
（２） Press △
△△
△ +
++
+ or ▽
▽▽
▽ -
--
- key to alter the value of Upper limit of High speed area.
Press
ENTER
ENTERENTER
ENTER key to set the value of Upper limit.
The display of
Upper limit of High speed area is changed 30 ⇔ 31 ･････ 60 ⇔ 30 .
Low Speed Gain
Speed-H1= ## Kt
Low Speed Gain
Speed-H2= ## Kt
