27-13
SM80B22M02E
１２． Option(Special) Data-1 setting
This data is composed of 16 bits and the setting is done by the hexadecimal number.
The available setting range is from [0000] to [FFFF].
Default setting : [0001]
In this setting, if gyrocompass failure alarm occurs during automatic steering (=NAVI or AUTO), the
rudder angle is maintained until steering mode is changed to manual mode (=HAND, RC or NFU).
（１）Press the
ENTER
ENTERENTER
ENTER
key after displayed "
Data-1(Hex)=####
" on the data display.
Data display becomes current setting mode.
←Cursor position is inputting point
（２）Press
△
△△
△
+
++
+
or
▽
▽▽
▽
-
--
-
key to set the cursor point. Then change the data by turning the Set
course dial. Turn to the clockwise direction, data is increased and turn to the counter clockwise
direction, data is decreased. (Data is 0 to 9 numbers)
（３）After input the flag, then press
ENTER
ENTERENTER
ENTER
key
To Next Page
