YOKOGAWA PT500 User Manual

2-31
SM80B22M02E
Selection data Contents
NMEA 0183:$xxHSC $xxHSC (Taker ID “xx” is not checked)
The first field data is used as the set course data.
The second field data should be “T”.
Super Bridge
For MITSUBISHI super bridge I/F
$xxTRC format
Taker ID “xx” should be either EC, EI, II or IN.
INS-1
For interfacing with ECDIS made by JRC
(Correspondence to a style approval previous ATOS version)
① $xxHTC
② $xxXTE
Taker ID “xx” should be either EC, EI, II or IN.
JRC CAT-B&C
(for MED TCS
(for MED TCS (for MED TCS
(for MED TCS
type approval
type approvaltype approval
type approval）
））
）
For interfacing with ECDIS made by JRC
The following four(4) messages are required.
① $xxHTC
② $xxXTE (set by XTE setting)
③ $xxHSC
④ $xxVDR
Taker ID “xx” should be either EC, EI, II or IN.
INS-2 (Type A) For interfacing with ECDIS made by FURUNO (At present, not
used.)
$xxHTC
Taker ID “xx” should be either EC, EI, II or IN.
Furuno CAT-B
(for MED TCS
(for MED TCS (for MED TCS
(for MED TCS
type approval
type approvaltype approval
type approval）
））
）
For interfacing with ECDIS made by FURUNO
The following two(2) messages are required.
① $xxHTC
② $xxVTG
Taker ID “xx” should be either EC, EI, II or IN.
Transas CAT-C
(for MED TCS
(for MED TCS (for MED TCS
(for MED TCS
type approval
type approvaltype approval
type approval）
））
）
For interfacing with ECDIS made by TRANSAS
$xxHTC
Taker ID “xx” should be either EC, EI, II or IN.
Kelvin INS-1 For interfacing with ECDIS made by KELVIN HUGHES
The following two(2) messages are required.
$xxHTC
Taker ID “xx” should be either EC, EI, II or IN.
Tokimec For interfacing with ECDIS made by TOKIMEC
$xxHTC
Taker ID “xx” should be either EC, EI, II or IN.
