Directions for Use of Image Creator
113
Operation Manual
Name Function
1 Image Display Area Displays acquired image.
2
“Call Back Last Image”
Button
Loads the RAW data, the last image acquired. Such operations can be done
on the loaded RAW data as reformulation and readjustment of tomographic
setting on the panoramic or Cephalometric radiographic images.
3 “New” Button
Acquires a new image from the patient. Such operations can be done on the
loaded RAW data as reformulation and readjustment of tomographic setting
on the panoramic or Cephalometric radiographic image.
4 “Select” Button
Loads a previously acquired RAW data. Such operations can be done on the
loaded RAW data as reformulation and readjustment of tomographic setting
on the panoramic or Cephalometric radiographic image.
5 “Settings” Button
Displays the Settings screen of the User Program Mode. In the User
Program Mode, the main equipment can be set up. For details, refer to "4
Directions for Use of Image Creator" P.110 .
6 Dental arch Size Group
When acquiring a new image, the size of tomographic trajectory is selected
for the panoramic image displayed in the preview and the panoramic image
to be newly created. After the image acquisition, the size of tomographic
trajectory is selected for the panoramic image to be reformulated when the
“Preview” Button is pressed. Select one from Small / Normal / Large.
* With Cephalometric image, dental arch can not be adjusted.
7 Dental arch Shape Group
When acquiring a new image, the shape of tomographic trajectory is selected
for the panoramic image displayed in the preview and the panoramic image
to be newly created. After the image acquisition, the shape of tomographic
trajectory is selected for the panoramic image to be reformulated when the
“Preview” Button is pressed. Select one from Narrow / Normal / Wide.
* With Cephalometric image, dental shape can not be adjusted.
8 Tomographic Position Group
When acquiring a new image, the position of tomographic trajectory
is selected for the panoramic image displayed in the preview and the
panoramic image to be newly created. After the image acquisition, the
position of tomographic trajectory is selected for the panoramic image to be
reformulated when the “Preview” Button is pressed. Select a position within
the range between -10.0 mm and +10.0 mm.
* With Cephalometric image, tomographic position can not be adjusted.
9 “ASC” Check box
When this box is checked, the cervical spine adjustment function is activated
when formulating the panoramic image. After image acquisition, cervical
spine adjustment (or lack thereof) is applied to the panoramic image
reconstructed by pressing Preview Button. This function can be used for
previously acquired images as well.
* With Cephalometric image, changes in cervical spine adjustment can not
be applied.
10 “Preview” Button
Using a previously acquired image, reformulates the panoramic image using
the settings in the items 6-9 above.
11 “Auto-Focus” Button
AutomaticallyfocusesontherectangulardomainspeciedattheImage
Display Area.
12 Display Adjustment Buttons
Adjusts the image display of the Image Display Area. The left-drag function
of the mouse changes according to the button pressed.
13 Coordinates Display
When the mouse cursor is on the Image Display area, the coordinates and
values of the pixel pointed at by the cursor are displayed. When a rectangular
domain is set, the starting and ending coordinates and the mean pixel value
of the selected area are displayed.
14
Image Acquisition
Information Display
Displays the information of the image at the Image Display area.
