YOSHIDA XP73 - Sensor Unit (Detachable)

Before Using this Product
34
Operation Manual
1.3.7 Sensor unit (detachable)
1
2
Name Function
1 Handle When docking station the sensor, hold the handle to retain it.
2 Knob for detaching Rotatetheknobtoxthesensortothedockingstation.
Locking/unlocking position of the knob for detaching
When locking When unlocking
* Caution
• Be sure to hold the handle when detaching the sensor. The sensor may drop if you hold
other parts. Dropping the sensor may cause failure.
• The sensor unit is equipped with a shock sensor. The shock sensor records any
excessive impact incurred, such as when the equipment falls down, and the equipment
will not qualify as being warrantable.
