1.3.2 Names and functions of control panel switches and indicators (1)
Each of the control panel switches executes its own function, moves the sliding mechanism
upordown,movesthearmunitforwardorbackward,speciesradiographysettings,
irradiates the positioning beam, etc. A buzzer will go off intermittently during X-ray exposure.
