Before Using this Product
25
Operation Manual
Name Function
24
Sensor unit (movable)
(**)
Converts X-ray absorption data into electronic data in response to the signals
from the controller during image acquisition to output to the PC. Depending
on each image acquisition mode, the internal driving mechanism slides the
sensor unit.
25
Headxatorfor3D
image acquisition (**)
This part is attached to chin rest base for accurate patient positioning while 3D
image acquisition.
* For equipment with Cephalometric
** For equipment with 3D function
*
1
TMJ (Temporomandibular Joint) mode: mandibular images
*
2
PCandMonitorarenotcontainedtothisproduct.Pleasepreparethem,whichfullltherequiredspecication
 describedinthe"11.1Specication"priortousingtheequipment.
Suppl. : Slide elevation mechanism
The elevation mechanism of the equipment is driven by an electric motor to
achieve 800 mm of stroke. For this reason, driving motor may generate slighly
large noise, however it is not the result of failure of the equipment.
