YOSHIDA XP73 - Stray Radiation Information; Dimensions of the Phantom Used; How to Test

MainSpecication
182
Operation Manual
11.10 Stray Radiation Information
Stray radiation dose at the water surface at the height of X-ray focal point.
11.10.1 Dimensions of the phantom used
Unit: mm
11.10.2 How To Test
1 Set measurement points with 500 mm intervals at the front, back, left, and right of the
equipment, making the rotation axis as the center.
(Measurementrange:(-1.5[m]to1.5[m])x(-1.5[m]to1.5[m]).(exceptthosemeasurement
points that are in contact with the equipment).
2 Adjust the dosimeter at the same height as the center line (focus height) of X-ray.
3 Place a cylindrical acrylic water tank (pictured above) at the rotation center as the imag-
ing subject.
4 Place the dosimeter at every measurement point, and measure the dose.
Image Acquisition
Conditions
Equipment
Conguration
Image Acquisition
Mode
Irradiation Conditions
TubeVoltage
(kV)
Tube Current
(mA)
Irradiation Time
(sec)
1
with
Cephalometric
Dental Mode 82 10.0 11.5
2
with
Cephalometric
Oral Mode 82 10.0 23.0
3
without
Cephalometric
Dental Mode 82 10.0 11.5
4
without
Cephalometric
Oral Mode 82 10.0 23.0
